- Customizable Trimslate shower bases with our unique adjustable depth threshold are designed so the maximum depth can be adjusted by up to 2-1/2-in without any trimming of the base
- Heavy Duty SMC Sheet Molding Compound Material
- Lightweight; natural stone effect
- Modern stainless steel drain cover conceals a conventional 2-in shower drain (not included)
- Trimslate bases can also be customized in the field to fit your space
- Bases can be trimmed up to 4-in in width away from either side of drain on center drain models and up to 4-in in width away from side opposite drain on end drain models or up to 2-in in depth away from drain without any loss of integrity
- One 80-in long add-on trimmable threshold is included
- The threshold has a 4-in wide flat surface to accommodate shower doors
- 1-in high aluminum tiling flange included
- Slip-resistant lightly textured slate floor maintains an easy-to-clean surface
- 10 Year Limited Residential / 3 Year Commercial Warranty
Guides & Documents | Installation PDF |
Brand | Samuel Mueller |
Product Type | Shower Base |
Collection | Trimslate |
Color | Dark Grey |
Width (in) | 48.5 to 51 |
Length (in) | 64.9 |
Height (in) | 2.75 |
Material | Sheet Molding Compound (SMC) |
Shape | Rectangular |
Color/Finish Family | Greys |
Weight (lb) | 93 |
Warranty | 10 Year Limited Residential / 3 Year Limited Commercial |
Ada Compliant | No |
Drain Assembly Included | No |
Drain Location | Center |
Drain Size (in) | 2 |
Installation | Alcove |
Integrated Seat | No |
Front to Back Dimension (in) | 45 to 50 |
Left To Right Dimension (in) | 61 to 65 |
Residential/Commercial | Residential and Commercial |
Series | Center Drain / Dark Grey |
Threshold | Single |
Threshold Height (in) | 2.75 |
